HT304 30HP 4WD Compact Tractor for Small Farms
The Hightop HT304 is a 30HP 4WD compact tractor built for small farms, orchards, and diversified operations where space is tight but work needs to get done. Its 1400kg chassis gives you the stability to handle everyday implements without wasting fuel on unnecessary bulk – making it a top choice among compact utility tractors for sale.
Pair it with standard Category 1 implements via the dual-speed 540/720 rpm PTO:
Orchard & Vineyard Work:Navigate between tree rows with ease. The adjustable wheelbase (1070-1270mm front / 1000-1300mm rear) and tight 2.5m turning radius make mowing, spraying, and hauling effortless.*
Small Farm Tasks:Till vegetable gardens, seed pastures, or clear snow with a full range of compatible attachments – from rotary tillers to post-hole diggers.*
Custom Options:Add an 8+8 shuttle shift for faster loader work, or upgrade to a canopy or ROPS frame for added safety and comfort.*
All at factory-direct wholesale pricing. Get your quote today!
Model | HT304 |
Type | 4X4 wheeled type |
Main dimensions | |
W XD X H (mm) | 2930X1500X2000 |
Wheel base (mm) | 1605/1730 |
Front wheel (mm) | 1070/1170/1270 Adjustable |
Rear wheel (mm) | 1000/1100/1200/1300 Adjustable |
Min. ground clearance (mm) | 330 |
Min. turning circle radius (m) | |
When one-side braking | 2.5±0.2 |
No braking | 2.9±0.2 |
Tractor dry mass (kg) | 1400 |
Front/Rear Ballast (kg) | 50/60 |
Max. PTO Power (kw) | 19.9 |
Transmission box | Mechanic gear box |
Gear shifts | (4+1)X2 |
Theoretical speed (km/h) | F2.07-31.54 R2.72-12.59 |
Differential | closed, 2 planetary gear |
Differential lock | Jaw type |
Diesel Engine | |
Model | 3T30 |
Type | Vertical 4 stroke, water cooled |
Number of Bores | 3 |
Bore dia. X stroke (mm) | 85X95 |
Combustion chamber | direct injection |
Rated Power (kw) | 22.06 |
Fuel consumption (g/kw.h) | ≤248.9g/kw.h |
Engine oil consumption (g/kw.h) | ≤2.04g/kw.h |
Front tyre size | 6.00-16 |
Rear tyre size | 9.50-24 |
Steering system | Power steering |
Brake | Shoe brake |
Tri-point Hitch system | Rear mounted, ball-hinged |
Max. lifting capacity (kN) | 4.96 |
PTO type | Rear mounted, nonindependent |
PTO Rev. (rpm) | 540/720 r/min |
Q1: Why is the 1400kg chassis weight important when shopping for new tractors for sale?
A: Horsepower alone cannot pull attachments if the wheels spin in the mud. The 1400kg heavy frame of the HT304 turns 30HP engine torque into solid ground friction, preventing wheel slip under load.
Q2: Does the HT304 accommodate standard Category 1 implements?
A: Yes. The rear three-point hitch is standard Category 1 size. It delivers a maximum lifting capacity of 4.96KN to lift mid-sized rotary cutters, seeders, and disc harrows easily.
Q3: Can the wheel track width be adjusted for specialized row crop management?
A: Yes. Both front and rear wheel tracks are adjustable (Front: 1070-1270mm / Rear: 1000-1300mm), allowing you to customize the stance to match your specific orchard or vine spacing.
