HT360W Skid Steer Loader
Wheeled skid steer loader utilizes the difference in linear speed between two wheels to realize vehicle steering, this steering mode makes the loader able to realize in-situ steering in a narrow space, with a very small steering radius, which is especially suitable for narrow field operation.
Chassis: wheeled walking mechanism, all-wheel drive, with good maneuverability and throughput, can adapt to a variety of complex terrain.
Engine: Output power is 8.5KW/3600rpm, providing power support for the work of the loader, featuring strong power and good fuel economy.
Working device: It can be equipped with many kinds of working devices, such as bucket, sweeper, milling machine, crushing hammer, forks, etc. The action of the working device is controlled by the hydraulic system, which can realize various working functions such as shoveling, digging, crushing, sweeping, etc.
| HT360W Skid Steer Loader — Parameter Table | ||
|---|---|---|
| Performance | ||
| Rated loading capacity | kg | 220 |
| Bucket volume | m³ | 0.09 |
| Maximum lifting force | kg | 375 |
| Working speed | km/h | 0-6.5 |
| Rated pressure | Mpa | 17 |
| Lifting time | S | 4.5 |
| Lowering time | S | 3.5 |
| Tipping time | S | 1.5 |
| Working weight | kg | 720 |
| Engine | ||
| Engine name | — | RATO Engine |
| Model | — | R420D |
| Type of engine | — | Gasoline Single Cylinder |
| Output power | — | 8.5KW(15hp)/3600rpm |
| Fuel consumption | L/h | ≤4.1 |
| Starting method | — | electric start |
| Fluid Capacity | ||
| Fuel tank | L | 6.7 |
| Engine oil | L | 1.1 |
| Hydraulic oil tank | L | 25 |
| Overall Dimension | ||
| Length x Width x Height | mm | 2400 × 1030 × 1330 |
| Packing size (wooden box) | mm | 1700 × 1050 × 1350 |
HT360W Skid Steer Loader FAQ
What is the difference between the HT360W and a compact track loader?
The HT360W uses a wheeled drive system, which offers faster travel on hard surfaces and lower maintenance compared with tracks. A compact track loader generally provides better traction on soft or uneven ground, but requires more maintenance and may damage delicate surfaces. The HT360W is more suitable for concrete, asphalt, and compacted gravel.
What is the rated load and maximum lifting force of the HT360W?
The HT360W has a rated load of 220 kg and a maximum lifting force of 375 kg. It is designed for light material handling, landscaping, and maintenance tasks.
What engine does the HT360W use? Is it gasoline or diesel?
The HT360W uses a RATO R420D single-cylinder gasoline engine with 8.5 kW (15 HP) at 3600 rpm and electric start. It does not use diesel fuel.
What is the hydraulic pressure of the HT360W?
The rated hydraulic pressure is 17 MPa. This supports stable operation for compatible attachments such as buckets, sweepers, and light-duty forks.
Can the HT360W fit through narrow gates and passages?
Yes. The overall width is 1030 mm, which allows it to pass through many narrow gates, garden paths, and confined areas where larger skid steer loaders cannot enter.
What attachments are compatible with the HT360W?
Common attachments include standard bucket, sweeper, light-duty forks, and other small hydraulic attachments. Please contact us with your specific attachment requirements to confirm compatibility.
Is the HT360W suitable for heavy digging or continuous earthmoving?
No. The HT360W is a compact, light-duty machine. For heavy digging or continuous earthmoving, a larger skid steer loader with higher rated load and hydraulic flow is recommended.
What is the MOQ and delivery time for the HT360W?
MOQ and delivery time depend on order quantity, configuration, and destination. Please contact our sales team for the latest MOQ, production schedule, and shipping details.
Can I customize the color or add my logo?
Yes. Custom color and logo options are available for bulk orders. Please confirm the details with our sales team before placing an order.
What maintenance does the HT360W require?
Regular maintenance includes checking engine oil, hydraulic oil level, tire pressure, and attachment connections. The gasoline engine should be serviced according to the RATO manual.
