HTCT35S-Ultra Crawler Tractor for Farm Operations
Choosing a Crawler Tractor Around the Actual Job
Professional agricultural buyers often need to evaluate more than engine output when selecting a tracked tractor. Ground conditions, implement compatibility, travel requirements and the ability to configure the machine for different operations can all affect the purchasing decision. HTCT35S-Ultra provides a defined crawler platform for buyers comparing equipment for commercial agricultural use.
A Tracked Layout for Varied Agricultural Terrain
The HTCT35S-Ultra has a 250 mm track width, 820 mm track gauge and 420 mm ground clearance. Its crawler configuration is specified for farmland cultivation, orchard management and other agricultural operations where tracked mobility is required. The maximum travel speed is 25 km/h, while the maximum climbing angle is specified at 30°.
Engine Options for Different Export Requirements
Two engine configurations are listed for the model: KM385BT with Euro 5 specification and KM385B with China Stage II specification. Their stated power ratings are 18.4 kW at 2400 rpm and 29 kW at 2200 rpm respectively. This gives overseas buyers a clear starting point when discussing the appropriate configuration for their destination market.
Implement Compatibility Matters in Multi-Task Purchasing
The HTCT35S-Ultra can be configured with listed implements including a bulldozer blade, loading bucket, excavator arm, ditching machine, harvester and rotary tiller. The rear PTO is a gearbox-type configuration operating at 330 rpm. Hydraulic specifications are 10 ml/r displacement and 18 MPa pressure, allowing buyers to compare the tractor with the requirements of their intended implements.
Specification-Based Procurement for Dealers and Contractors
With an unladen weight of 920 kg and overall dimensions of 2300 × 1120 × 1500 mm, the HTCT35S-Ultra gives agricultural machinery dealers, contractors and professional farming businesses a defined machine configuration to evaluate. International buyers can request an export quotation with the target market, engine option, attachment requirements and order quantity. Spare parts support, shipping assistance and dealer cooperation can also be discussed during procurement.
| Parameter | Specification |
|---|---|
| Model | HTCT35S-Ultra |
| Machine Type | Crawler Tractor |
| Overall Dimensions (L × W × H) | 2300 × 1120 × 1500 mm |
| Engine Options | KM385BT (Euro 5) KM385B (China Stage II) |
| Engine Power | 18.4 kW / 2400 rpm 29 kW / 2200 rpm |
| Starting Method | Electric Start |
| Unladen Weight | 920 kg |
| Ground Clearance | 420 mm |
| Track Gauge | 820 mm |
| Track Length | 1000 mm |
| Track Width | 250 mm |
| Maximum Travel Speed | 25 km/h |
| Maximum Climbing Angle | 30° |
| Gearbox Ratios | 6 Forward Gears / 2 Reverse Gears |
| Steering Control Method | Mechanical Steering |
| Steering System | Single-side Independent Braking |
| Hydraulic System Displacement | 10 ml/r |
| Hydraulic System Pressure | 18 MPa |
| Maximum Tractive Force | 6 kN |
| Rear Power Take-Off Configuration | Gearbox Type |
| Rear Power Take-Off Speed | 330 rpm |
| Rear Coupling Spacing | 110 × 170 mm |
| Compatible Attachments | Bulldozer Blade, Loading Bucket, Excavator Arm, Ditching Machine, Harvester, Rotary Tiller |
FAQ About HTCT35S-Ultra Crawler Tractor
What should buyers consider when selecting the HTCT35S-Ultra?
Buyers should compare the required engine configuration, working conditions, attachment type, PTO requirements, hydraulic specifications and destination-market requirements. These factors help determine whether the listed machine configuration matches the intended operation.
What engine configurations are available for the HTCT35S-Ultra?
The model is listed with two engine options: KM385BT with Euro 5 specification and KM385B with China Stage II specification. Their stated power outputs are 18.4 kW at 2400 rpm and 29 kW at 2200 rpm.
Why are there two engine options for this crawler tractor?
The two listed configurations provide different specifications for export and operating requirements. Buyers should identify the destination market and applicable engine or emission requirements before confirming the preferred version.
What is the ground clearance of the HTCT35S-Ultra?
The specified ground clearance is 420 mm. This is one of the key dimensional specifications buyers can use when evaluating the tractor for agricultural terrain and field conditions.
What is the maximum travel speed?
The HTCT35S-Ultra has a specified maximum travel speed of 25 km/h. Actual operating speed depends on the working environment and operating conditions.
What implements can be matched with the HTCT35S-Ultra?
The listed compatible implements include a bulldozer blade, loading bucket, excavator arm, ditching machine, harvester and rotary tiller. The required implement should be confirmed with the machine configuration before ordering.
Can the HTCT35S-Ultra work with a rotary tiller?
Yes. A rotary tiller is included in the official list of compatible attachments. Buyers should confirm the complete implement configuration and PTO requirements for the intended application.
What PTO specification should buyers check?
The rear PTO uses a gearbox-type configuration and has a specified speed of 330 rpm. Buyers should compare this specification with the requirements of the agricultural implement they intend to use.
What hydraulic specifications are provided?
The official specification lists hydraulic system displacement at 10 ml/r and hydraulic system pressure at 18 MPa. These values should be considered when evaluating hydraulic attachment compatibility.
Is the HTCT35S-Ultra suitable for professional agricultural contractors?
The official product page positions the model for agricultural contractors, equipment dealers and professional farming users. Its multiple listed attachments allow buyers to evaluate one crawler platform for different agricultural operations.
What is the unladen weight of the HTCT35S-Ultra?
The specified unladen weight is 920 kg. For export transportation, buyers should confirm the final machine configuration and shipping arrangement when requesting a quotation.
Can overseas dealers request an HTCT35S-Ultra quotation?
Yes. Dealers, distributors and professional equipment buyers can request an export quotation by providing the destination market, required engine configuration, attachment requirements and order quantity. Spare parts support, shipping assistance and dealer cooperation can also be discussed.
