HT-10BZ Mini Excavator
The HT-10BZ 1-ton mini excavator for sale is a high-efficiency compact digger featuring a boom side swing for precision trenching and foundation work in confined spaces. Powered by a reliable Koop engine, this small hydraulic excavator offers a portable yet durable solution that ensures a superior ROI for rental fleets and landscaping contractors. Inquire today for factory-direct wholesale pricing and professional B2B support on our versatile range of mini crawler excavators.
Email:info009@hightopgroup.com
Phone:+86 181 6205 2962
Parameter
Images
Details images
Parameter
| HT-10BZ Mini Excavator — Parameter Table | |
|---|---|
| Basic Parameters | |
| Model | HT10BZ |
| Weight | 1000kg |
| Digging bucket capacity | 0.025cbm / 120kg |
| Bucket width | 380mm |
| Engine | |
| Engine | B&S Gasoline engine / Koop |
| Rated power | 10.1kw / 7kw |
| Displacement | 0.211 L |
| Bore stroke | 70x55 |
| Hydraulic System | |
| Displacement | 6.8ml/r |
| Travel speed | 1.5km/h |
| Dimensions (Unit: mm) | |
| Overall dimension (L × W × H) | 2900 × 900/930 × 2180 mm |
| Wheelbase | 910 mm |
| Total length of track | 1230mm |
| Platform ground clearance | 380 mm |
| Platform back turning radius | 784 mm |
| Chassis width | 896 mm |
| Track width | 180 mm |
| Chassis ground clearance | 132 mm |
| Track height | 320 mm |
| Working Range (Unit: mm) | |
| Max. Digging depth | 1750 mm |
| Max. Vertical digging depth | 1550 mm |
| Max. Digging height | 2610 mm |
| Max. Dumping height | 1850 mm |
| Max. Digging radius on ground | 3050 mm |
| Min. Rotation radius | 1330 mm |
| Bulldozer Blade (Unit: mm) | |
| Max. Upgrade height of bulldozer blade | 345 mm |
| Max. Digging depth of bulldozer blade | 255 mm |
